Nidec HD75V3B - TEFC, 3 Phase, 75 HP
Normally In Stock
Code: 312503
Nidec HD75V3B - Totally Enclosed Fan Cooled - 3 Phase - 75 HP - 1200 RPM - 405T Frame - 60 Hz - 460 Max Volt - INVERTER GRADE® Insulation - Cast Iron
Condition: New
Usually ships Same Day or Next Day$10702.88
Sale Price
$8919.07
Tariff Status
Tariff may apply if shipping to the United States. Tariff costs are calculated and will be displayed in the shopping cart.
Need a large quantity or a custom solution?
Add this product to your job, favorites list or request a quick quote for volume pricing and lead time information. Our team is ready to assist with any special requirements.
Description
Nidec HD75V3B - Introducing the Definite Purpose Three Phase Totally Enclosed Fan Cooled (TEFC) World Motor HOSTILE DUTY®. This motor is designed for demanding applications requiring variable torque and constant torque. With an Inverter Grade® Insulation System, Class F thermostats, and shaft grounding ring, it ensures reliable and safe operation. The motor features a corrosion-resistant mill and chemical duty paint, cast iron construction, and stainless steel nameplate for durability. It offers dual voltage capability, NEMA® Design B performance, and regreasable ball bearings. With a wide range of features including constant horsepower, field convertibility, and various conversion kits, it is ideal for pumps, fans, blowers, and inverter-powered applications. Upgrade your industrial equipment with The dependable and versatile Definite Purpose Three Phase Totally Enclosed Fan Cooled (TEFC) World Motor HOSTILE DUTY®.
Specifications
Motor Enclosure Type
Totally Enclosed Fan Cooled
Motor Voltage Phases
3 Phase
Motor Horsepower
75 HP
Motor Frame Model
405T
Motor RPM's
1200 RPM
Motor Voltage
230 Volt
Motor Voltage
460 Volt
Motor Construction
Cast Iron
Manufacturer
Nidec
Motor Insulation Class
INVERTER GRADE® Insulation
Features
Inverter Grade® Insulation System (Meets NEMA®† MG-1 Part 31)
Class F Thermostats (One Per Phase)
Shaft Grounding Ring
Corrosion Resistant Mill & Chemical Duty Paint
Cast Iron Frame, Cast Iron End Brackets
Stainless Steel Nameplate & Zinc Plated Hardware
Shaft Slinger On Pulley End For IP54 Protection
Dual Voltage 230/460 Volts (1-100 HP)
40°C Ambient, NEMA®† Design B Performance On 60 Hz Sine Wave Power
Regreasable Ball Bearings 250 Frame & Up, Lifting Provisions
Double Shielded Bearings 140-360, Open On 400-440
Double Dip & Bake With Extra Bracing
Class F Insulation, 1.15 S.F. On Sine Wave / 1.0 S.F. On PWM
Constant Horsepower To 90 Hz
Steel Fan Cover & Conduit Box
Field Convertible To F2 Mounting
Condensation Drains With Plastic Plugs
Conversion Kits: All Cast Iron Upgrade, C&D Flanges, Canopy Kits
C-Face Footed 1-5 HP
Bearing Caps On 400-440
Non-Drive End Insulated Bearing On 400-440
