Lovato ADXNF045 Compact Soft Starter - 15-40 HP, 45 Amp, 208-600 VAC
Normally In Stock
Code: 642734
Lovato ADXNF045 - Ultra compact, two phase control, 15 HP @ 230 V, 30 HP @ 400 V, 40 HP @ 500 V, 45 Amp, 208-600 VAC
Condition: New
Usually Ships Same Day or Next DayMUST ORDER A MINIMUM OF $250 FROM LOVATO FOR PRODUCT TO SHIP
$904.52
Sale Price
$753.77
Tariff Status
Tariff may apply if shipping to the United States. Tariff costs are calculated and will be displayed in the shopping cart.
Need a large quantity or a custom solution?
Add this product to your job, favorites list or request a quick quote for volume pricing and lead time information. Our team is ready to assist with any special requirements.
Description
Lovato ADXNF045 Compact Soft Starter - 15-40 HP, 45 Amp, 208-600 VAC - Soft starter, ADXNF... type, NFC version, with integrated by-pass relay, built-in fan. Auxiliary supply 100...240VAC. Rated operational voltage 208...600VAC, 45A, password
Specifications
Starter Horsepower
15 HP @ 230 V
Manufacturer
Lovato
Component
Compact Soft Starter
Starter Current Rating
45 Amp
Starter Voltage Range
208-600 VAC
Starter Horsepower
30 HP @ 400 V
Starter Horsepower
40 HP @ 500 V
Features
Two phase control
For standard duty
IEC rated soft starter current Ie 6...45A
IEC rated motor power 2.2...22kW (400VAC)
Rated operational voltage 208...600VAC
Version with auxiliary supply voltage 24VAC/DC or 100...240VAC
Built-in bypass relay
Starting with voltage ramp
Basic version with parameter setting with potentiometers on front
Version with NFC connectivity for the programming with smartphone and App
Advanced version with potentiometers and NFC connectivity, optical port, integrated motor thermal protection and optional RS485 module, Modbus-RTU protocol
Integrated protections for the motor and soft starter
LEDs for status signaling and diagnostics
Compact housing, 45mm width
Screw fixing or 35mm DIN rail mounting
cULus certification.
