EMG 17-REL/KSR- 48/21-21-LC Phoenix Contact 2917405 Timed relay 1floatingPDT
Code: 69045
Phoenix 2917405 Timed relay 1floatingPDT 24 VDC (19.2 VDC ...30 VDC) Screw connection Relays
This product is now obsolete from the manufacturer
Below are replacement products designated by the manufacturer. See description and specs to assure they will work for your application.
Replacement Products
Description
Timer relay with switch-on delay (voltage-controlled) and an adjustable time range (3 min - 300 min), with screw connection
Specifications
Relay Throws
Double Throw
Relay Mounting
Din Rail
Relay Connection Type
Screw Connection
Floating (Isolated Dry Contacts)
Floating Isolated Contacts
Relay Poles
Single Pole
Relay Timing Range
3
Manufacturer
Phoenix Contact
Component
Timer Relay
Coil Voltage Rating
12-24 Volt
Features
High level of setting accuracy thanks to labeled and illuminated thumb wheel
6.2 mm narrow design width
Downloads
Phoenix 2917405 CAD data International.dxfPhoenix 2917405 CAD data International.pdfPhoenix 2917405 CAD data International.stpPhoenix 2917405 Data Sheet English.pdfPhoenix 2917405 Manufacturers declaration English.pdfPhoenix 2917405 Manufacturers declaration International.pdfPhoenix 2917405 Package Slip International.pdfPhoenix 2917405 Tender Text English.zip
