Phoenix Contact 1829085 PCB header MC 1,5/16-G-3,81 P20 THR
Normally In Stock
Code: 142403
Phoenix Contact 1829085 MC 1,5/16-G-3,81 P20 THR ,Copper Alloy,LCP,IIIa Printed-circuit board connector *NON-CANCELLABLE, NON-RETURNABLE*
Condition: New
Usually ships within 7-14 days. Call for ship time$7.78
Sale Price
$6.48
MUST BUY IN PACKS OF 50
Tariff Status
Tariff may apply if shipping to the United States. Tariff costs are calculated and will be displayed in the shopping cart.
Need a large quantity or a custom solution?
Add this product to your job, favorites list or request a quick quote for volume pricing and lead time information. Our team is ready to assist with any special requirements.
Description
Phoenix Contact 1829085 The PCB headers have a nominal cross-sectional area of 1.5 mm² and are colored black with a rated voltage of 160V at an maximum current of 8A. They feature Sn contact surfaces, linear pinning, and a pitch of 3.81mm, suitable for soldering or wave soldering mounting.
Specifications
Connector Amperage
8 Amp
Connector Material
Iiia
Connector Material
LCP
Connector Voltage
2.5 Kv
Connector Voltage
2.95 Kv
Connector Voltage
1.39 Kv
Connector Material
Copper Alloy
Manufacturer
Phoenix Contact
Number of Connections
16
Number of Positions
16
Component
PCB
Sub Component
PCB Header
Connector Voltage
160 Volt
Connector Voltage
250 Volt
Features
Designed for integration into the SMT soldering process
Maximum flexibility when it comes to device design – one header for connectors with different connection technologies
