Images are for illustration only and may not reflect the actual product. Refer to the description or specs.
Phoenix Contact 3211236 Fuse holder UK 10,3-HESI 1000V
Normally In Stock
Code: 40826
UK 10,3-HESI 1000V Phoenix Contact 3211236 Fuse modular Terminal Block - UK 10,3-HESI 1000V - Fuse type: Glass Screw Connection 1 Level 18 mm with 2 Connections. Not Grounded, Fused Black. 1000 Volt, 30 Amp max rating.
Condition: New
Usually Ships Same day or Next Day$41.59
Sale Price
$34.66
MUST BUY IN PACKS OF 10
Tariff Status
Tariff may apply if shipping to the United States. Tariff costs are calculated and will be displayed in the shopping cart.
Need a large quantity or a custom solution?
Add this product to your job, favorites list or request a quick quote for volume pricing and lead time information. Our team is ready to assist with any special requirements.
Related Products
Description
Phoenix Contact 3211236 The fuse holder is designed to accommodate a glass or ceramic fuse with specific dimensions, including length and width. It meets international standards for fuse holders (60269-6) and can handle a nominal voltage of 1000V DC and a maximum current of 30A. The connection method involves screwing the fuse into place, while the rated cross-sectional area is 16mm2, with a minimum and maximum value of 1.5mm2 to 25mm2. Two mounting types are supported: NS35/7.5 and NS35/15, and the holder itself has a black color.
Specifications
Terminal Block Indication
No Indicator
Terminal Block Voltage Rating
1000 Volt
Terminal Block Fused
Fused
Terminal Block Width
18 mm
Terminal Block Number of Levels
1
Terminal Block Number of Connections
2
Terminal Block Connection Method
Screw Connection
Terminal Block Grounded
Not Grounded
Terminal Block Component Color
Black
Terminal Block Min Wire Size
16
Terminal Block Amperage
30 Amp
Terminal Block Fuse Type
10:3 x 38 mm
Terminal Block Max Wire Size
3
Component
Terminal block
Manufacturer
Phoenix Contact
Sub Component
Fuse terminal block
Sub Component
Fuse Modular Terminal Block
