Images are for illustration only and may not reflect the actual product. Refer to the description or specs.
Phoenix Contact 3071358 Trunk line branch terminal UDB 2X25/16 BU
Normally In Stock
Code: 41474
UDB 2X25/16 BU Phoenix Contact 3071358 Trunk line branch Terminal - UDB 2X25/16 BU Screw Connection 1 Level 23 mm with 4 Connections. Not Grounded, Not Fused Blue. 400 Volt, 101 Amp max rating.
Condition: New
Usually Ships Same day or Next Day$16.64
Sale Price
$13.87
MUST BUY IN PACKS OF 5
Tariff Status
Tariff may apply if shipping to the United States. Tariff costs are calculated and will be displayed in the shopping cart.
Need a large quantity or a custom solution?
Add this product to your job, favorites list or request a quick quote for volume pricing and lead time information. Our team is ready to assist with any special requirements.
Related Products
Description
Phoenix Contact 3071358 The branch terminal has a nominal voltage of 400V and a current of 101A, with four connections at one position using screw connections. The cross-sectional area ranges from 1.5mm2 to 25mm2 across two levels, connected via screw connections, and mounted using the NS35/7.5 and NS35/15 mounting types in blue color.
Specifications
Terminal Block Indication
No Indicator
Terminal Block Voltage Rating
400 Volt
Terminal Block Fused
Not Fused
Terminal Block Width
23 mm
Terminal Block Number of Levels
1
Terminal Block Number of Connections
4
Terminal Block Component Color
Blue
Terminal Block Connection Method
Screw Connection
Terminal Block Grounded
Not Grounded
Terminal Block Max Wire Size
2
Terminal Block Min Wire Size
8
Terminal Block Amperage
101 Amp
Jumper Number of Positions
1
Component
Terminal block
Manufacturer
Phoenix Contact
Sub Component
Feed-through terminal block
Sub Component
Trunk Line Branch Terminal
