Phoenix Contact 3244470 Initiator/actuator terminal block PTIO 1,5/S/5
Normally In Stock
Code: 42456
PTIO 1,5/S/5 Phoenix Contact 3244470 Sensor/actuator Terminal Block - PTIO 1,5/S/5 Push-In Connection 1 Level 3.5 mm with 5 Connections. Not Grounded, Not Fused Gray. 250 V, 13.5 A max rating.
Condition: New
Usually ships within 7-14 days. Call for ship time.$6.74
Sale Price
$5.62
MUST BUY IN PACKS OF 50
Tariff Status
Tariff may apply if shipping to the United States. Tariff costs are calculated and will be displayed in the shopping cart.
Need a large quantity or a custom solution?
Add this product to your job, favorites list or request a quick quote for volume pricing and lead time information. Our team is ready to assist with any special requirements.
Description
Phoenix Contact 3244470 The terminal block features an initiator/actuator terminal with a nominal voltage of 250V and a nominal current rating of 13.5A, accommodating up to seven connections via push-in connection method, rated for cross sections between 0.14mm2 and 1.5mm2, and is mounted using the NS35/7,5 or NS35/15 mounting types in a gray color.
Specifications
Terminal Block Voltage Rating
250 Volt
Terminal Block Fused
Not Fused
Terminal Block Number of Levels
1
Terminal Block Width
3.5 mm
Terminal Block Number of Connections
5
Terminal Block Component Color
Gray
Terminal Block Grounded
Not Grounded
Terminal Block Connection Method
Push-in Connection
Component
Terminal block
Manufacturer
Phoenix Contact
Terminal Block Amperage
13.5 Amp
Sub Component
Sensor-Acuator Terminal Block
