Eaton E47CMS10 Precision Limit Switch
Normally In Stock
Code: 449252
Eaton E47CMS10 - Precision Limit Switch, E47, Roller plunger, Screw Terminals, 20A at 250 Vac, 6A at 30 Vdc, 0.01 mm/s-1m/s, 1-SPDT (Form C)
Condition: New
Usually ships Same Day or Next Day$83.82
Sale Price
$69.85
Tariff Status
Tariff may apply if shipping to the United States. Tariff costs are calculated and will be displayed in the shopping cart.
Need a large quantity or a custom solution?
Add this product to your job, favorites list or request a quick quote for volume pricing and lead time information. Our team is ready to assist with any special requirements.
Description
Eaton E47CMS10 - E47 Precision Switches, part of Eaton's electrical sector, offer cost-effective high-accuracy switching. These switches provide customization options for various standard features, including current capacity, operating force, travel characteristics, and actuators, ensuring a tailored fit for your specific application. They come in compact basic forms, ideal for space-restricted environments, or rugged, metal housings. Notable features include precision snap-action operators for accurate repeatability of electrical and mechanical operating characteristics, a high current capacity of up to 20A for power load switching and motor handling, and enclosed booted versions that shield actuators from debris. These switches are a versatile choice for precise and reliable electrical control.
Specifications
(Instrument-Sensor) Connection Type
Screw Terminal
(Instrument-Sensor) IP Protection
IP67
(Instrument-Sensor) IP Protection
IP69K
(Instrument-Sensor) NEMA Protection
NEMA 1
Manufacturer
Eaton
(Instrument-Sensor) Temperature Range
-13 °F - 176 °F
(Instrument-Sensor) Actuator
Plunger
Line
E47
(Instrument-Sensor) Contact Configuration
SPDT
(Instrument-Sensor) Contact Rating
6 Amp at 30 VDC
(Instrument-Sensor) Enclosure Composition
Mineral Filled Phenolic
(Instrument-Sensor) Contact Rating
20 Amp at 250 VAC
Component
Precision Switch
Features
Compact housings are ideal for applications where space is restricted.
Precision snap-action operators provide accurate repeatability of electrical and mechanical operating characteristics
High current capacity (up to 20 A) allows for power load switching and motor handling capability
Enclosed booted versions shield actuators from debris
