Dwyer DPML-503P LCD Digital Panel Meter
Normally In Stock
Code: 570889
Dwyer DPML-503P - LCD Digital panel meter with power engineering units, voltage powered 12 VDC/24 VDC, red segments.
Condition: New
Usually ships Same Day or Next Day$212.81
Sale Price
$177.34
Tariff Status
Tariff may apply if shipping to the United States. Tariff costs are calculated and will be displayed in the shopping cart.
Need a large quantity or a custom solution?
Add this product to your job, favorites list or request a quick quote for volume pricing and lead time information. Our team is ready to assist with any special requirements.
Description
Dwyer DPML-503P is an LCD Digital Panel Meter with an accuracy of ±(0.1% FS + 2 count). It has a temperature range of 32 to 122°F, and voltage options of 12 VDC or 24 VDC. The meter features a 4-1/2 digit, 7-segment display with adjustable zero and span adjustments. It has snap-in bezel mounting and screw terminal connections. The input options include 4-20 mA or 0-200 mVDC, 0-5 VDC, or 0-10 VDC. The meter has 4-position selectable decimal points and a conversion rate of 3 per second. The backlit display is powered by 24 VDC @ 35 mA.
Specifications
Component
Digital Panel Meter
Manufacturer
Dwyer
(Instrument-Sensor) Measurement Accuracy
0.10%
Sub Component
LCD
(Instrument-Sensor) Temperature Range
32 - 122°F/0 - 50°C
Features
Panel mount for quick installation
3-1/2 or 4-1/2 digit with 0.45˝ or 1˝ segments
Colored segments available in black, red, amber, green, or blue
Jumper selectable engineering units and decimal point positions
