Dwyer DPMP-403 LCD Digital Panel Meter
Normally In Stock
Code: 570898
Dwyer DPMP-403 - LCD digital process meter, loop powered 4 to 20 mA, red segments.
Condition: New
Usually ships Same Day or Next Day$171.85
Sale Price
$143.21
Tariff Status
Tariff may apply if shipping to the United States. Tariff costs are calculated and will be displayed in the shopping cart.
Need a large quantity or a custom solution?
Add this product to your job, favorites list or request a quick quote for volume pricing and lead time information. Our team is ready to assist with any special requirements.
Description
Dwyer DPMP-403 is a snap-in LCD digital panel meter with an operating temperature range of 32 to 122°F (0 to 50°C). It offers adjustable zero and span adjustments (±1999 counts), and an accuracy of ±(0.1% FS + 2 count). With a 3-1/2 digit display and screw terminals for connections, it is available in two voltage options: DPMP-4XX(P) powered by control loop or DPMP-5XX(P) with 12 or 24 VDC. The input options for DPMP-4XX(P) are 4 to 20 mA, while DPMP-5XX(P) supports 0 to 200 mVDC, 0 to 5VDC, or 0 to 10VDC. It has a conversion rate of 3 per second and is suitable for various engineering units. The backlight is powered by 24 VDC @ 35 mA, and it automatically displays "-" for polarity.
Specifications
Component
Digital Panel Meter
Manufacturer
Dwyer
(Instrument-Sensor) Measurement Accuracy
0.10%
Sub Component
LCD
(Instrument-Sensor) Temperature Range
32 - 122°F/0 - 50°C
Features
Panel mount for quick installation
3-1/2 or 4-1/2 digit with 0.45˝ or 1˝ segments
Colored segments available in black, red, amber, green, or blue
Jumper selectable engineering units and decimal point positions
