Dwyer DPMP-502P LCD Digital Panel Meter
Normally In Stock
Code: 570907
Dwyer DPMP-502P - LCD Digital panel meter with power engineering units, voltage powered 12 VDC/24 VDC, green segments.
Condition: New
Usually ships Same Day or Next Day$175.48
Sale Price
$146.23
Tariff Status
Tariff may apply if shipping to the United States. Tariff costs are calculated and will be displayed in the shopping cart.
Need a large quantity or a custom solution?
Add this product to your job, favorites list or request a quick quote for volume pricing and lead time information. Our team is ready to assist with any special requirements.
Description
Dwyer DPMP-502P is an LCD Digital Panel Meter with a temperature range of 32 to 122°F (0 to 50°C). It has an accuracy of ±(0.1% FS + 2 count) and adjustable zero and span adjustments (±1999 Counts). The meter has a snap-in bezel mount and a 3-1/2 digit, 7 segment display. It has screw terminals for connections and accepts different input voltages depending on the model. The DPMP-4XX(P) model is powered by the control loop and the DPMP-5XX(P) model can be powered by 12 VDC or 24 VDC. The meter has 3-position selectable decimal points, a conversion rate of 3 per second, and a warm-up time of 10 minutes. It has automatic polarity with "-" displayed and a backlight power supply of 24 VDC @ 35 mA typical.
Specifications
Component
Digital Panel Meter
Manufacturer
Dwyer
(Instrument-Sensor) Measurement Accuracy
0.10%
Sub Component
LCD
(Instrument-Sensor) Temperature Range
32 - 122°F/0 - 50°C
Features
Panel mount for quick installation
3-1/2 or 4-1/2 digit with 0.45˝ or 1˝ segments
Colored segments available in black, red, amber, green, or blue
Jumper selectable engineering units and decimal point positions
