Dwyer DPMW-403 LCD Digital Panel Meter
Normally In Stock
Code: 570916
Dwyer DPMW-403 - DPMW-403 4-20 MA RED #/BLK
Condition: New
Usually ships Same Day or Next Day$184.87
Sale Price
$154.06
Tariff Status
Tariff may apply if shipping to the United States. Tariff costs are calculated and will be displayed in the shopping cart.
Need a large quantity or a custom solution?
Add this product to your job, favorites list or request a quick quote for volume pricing and lead time information. Our team is ready to assist with any special requirements.
Description
Dwyer DPMW-403 is an LCD digital panel meter with a temperature range of 32 to 122°F (0 to 50°C) and an accuracy of ±(0.1% FS + 2 count). It has adjustable zero and span adjustments (±1999 counts) and a snap-in bezel mount. The meter features a 3-1/2 digit, 7-segment display and screw terminals for connections. It is available in two voltage options (DPMP-4XX(P): Powered by control loop; DPMP-5XX(P): 12 VDC or 24 VDC) and offers multiple input options (DPMP-4XX(P): 4 to 20 mA; DPMP-5XX(P): 0 to 200 mVDC, 0 to 5 VDC, or 0 to 10 VDC). The meter also has user-selectable decimal points, a conversion rate of 3 per second, and a 10-minute warm-up time. It automatically displays "-" for negative values and has a 24 VDC backlight power supply.
Specifications
Component
Digital Panel Meter
Manufacturer
Dwyer
(Instrument-Sensor) Measurement Accuracy
0.10%
Sub Component
LCD
(Instrument-Sensor) Temperature Range
32 - 122°F/0 - 50°C
Features
Panel mount for quick installation
3-1/2 or 4-1/2 digit with 0.45˝ or 1˝ segments
Colored segments available in black, red, amber, green, or blue
Jumper selectable engineering units and decimal point positions
