Dwyer DPMA-401 LCD Digital Process Meter
Normally In Stock
Code: 571618
Dwyer DPMA-401 - LCD Digital panel meter, loop powered 4 to 20 mA, amber segments.
Condition: New
Usually ships Same Day or Next Day$241.84
Sale Price
$201.53
Tariff Status
Tariff may apply if shipping to the United States. Tariff costs are calculated and will be displayed in the shopping cart.
Need a large quantity or a custom solution?
Add this product to your job, favorites list or request a quick quote for volume pricing and lead time information. Our team is ready to assist with any special requirements.
Description
Dwyer DPMA-401 is a compact LCD Digital Process Meter with a temperature range of 32 to 122°F (0 to 50°C). It offers ±(0.05% FS + 1 count) accuracy, adjustable zero and span adjustments, and 3-1/2 digit, 7 segment display. The meter can be powered by a control loop or 12VDC/24VDC and is available in snap-in panel mount or clamp mounting options. It has various input options such as 4-20mA, 0-200mVDC, 0-5VDC, or 0-10VDC and supports engineering units like °F, °C, %, psi, V, A, KW, and PF. The meter also features automatic polarity, user-selectable decimal points, and a backlight power supply of 24VDC @ 35mA.
Specifications
Component
Digital Panel Meter
Manufacturer
Dwyer
Sub Component
LCD
(Instrument-Sensor) Temperature Range
32 - 122°F/0 - 50°C
(Instrument-Sensor) Measurement Accuracy
0.05%
Features
Panel mount for quick installation
3-1/2 or 4-1/2 digit with 0.45˝ or 1˝ segments
Colored segments available in black, red, amber, green, or blue
Jumper selectable engineering units and decimal point positions
Downloads
Code: 571618
Dwyer DPMA-401 LCD Digital Process Meter
$241.84
Sale Price
$201.53
