Dwyer DPMA-500P LCD Digital Process Meter
Normally In Stock
Code: 571626
Dwyer DPMA-500P - DPMA-500P VOLT CONT NO BKLITE
Condition: New
Usually ships Same Day or Next Day$225.50
Sale Price
$187.92
Tariff Status
Tariff may apply if shipping to the United States. Tariff costs are calculated and will be displayed in the shopping cart.
Need a large quantity or a custom solution?
Add this product to your job, favorites list or request a quick quote for volume pricing and lead time information. Our team is ready to assist with any special requirements.
Description
Dwyer DPMA-500P is an LCD Digital Process Meter with a temperature range of 32 to 122°F (0 to 50°C) and an accuracy of ±(0.05% FS + 1 count). It has adjustable zero and span adjustments (±1999 counts) and can be powered by a control loop or 12/24 VDC. The meter can be snap-in panel mounted or clamped with a 3-1/2 digit, 7 segment display and screw terminals for connection. It has various input options and supports units such as °F, °C, %, psi, V, A, KW, PF.
Specifications
Component
Digital Panel Meter
Manufacturer
Dwyer
Sub Component
LCD
(Instrument-Sensor) Temperature Range
32 - 122°F/0 - 50°C
(Instrument-Sensor) Measurement Accuracy
0.05%
Features
Panel mount for quick installation
3-1/2 or 4-1/2 digit with 0.45˝ or 1˝ segments
Colored segments available in black, red, amber, green, or blue
Jumper selectable engineering units and decimal point positions
Downloads
Code: 571626
Dwyer DPMA-500P LCD Digital Process Meter
$225.50
Sale Price
$187.92
