Dwyer DPMA-501 LCD Digital Process Meter
Normally In Stock
Code: 571627
Dwyer DPMA-501 - LCD Digital panel meter, voltage powered 12 VDC/24 VDC, amber segments.
Condition: New
Usually ships Same Day or Next Day$241.84
Sale Price
$201.53
Tariff Status
Tariff may apply if shipping to the United States. Tariff costs are calculated and will be displayed in the shopping cart.
Need a large quantity or a custom solution?
Add this product to your job, favorites list or request a quick quote for volume pricing and lead time information. Our team is ready to assist with any special requirements.
Description
Dwyer DPMA-501 is an LCD Digital Process Meter that displays temperature readings from 32 to 122°F (0 to 50°C) with an accuracy of ±(0.05% FS + 1 count). It has adjustable zero and span adjustments, mounting options, a 3-1/2 digit, 1" H display, and screw terminals for easy connection. The input options are 4 to 20 mA or 0 to 200 mVDC, 0 to 5 VDC, or 0 to 10 VDC. The unit has a 10-minute warm-up, automatic polarity, and a 3-position decimal point selector.
Specifications
Component
Digital Panel Meter
Manufacturer
Dwyer
Sub Component
LCD
(Instrument-Sensor) Temperature Range
32 - 122°F/0 - 50°C
(Instrument-Sensor) Measurement Accuracy
0.05%
Features
Panel mount for quick installation
3-1/2 or 4-1/2 digit with 0.45˝ or 1˝ segments
Colored segments available in black, red, amber, green, or blue
Jumper selectable engineering units and decimal point positions
