Phoenix Contact 1600030 Female insert HCC 4-FC
Normally In Stock
Code: 63322
HCC 4-FC Phoenix 1600030 High current terminal block Crimp connection 400 V 13.5 Amp gray Terminal Blocks
Condition: New
Usually Ships Same day or Next Day$16.31
Sale Price
$13.59
MUST BUY IN PACKS OF 50
Tariff Status
Tariff may apply if shipping to the United States. Tariff costs are calculated and will be displayed in the shopping cart.
Need a large quantity or a custom solution?
Add this product to your job, favorites list or request a quick quote for volume pricing and lead time information. Our team is ready to assist with any special requirements.
Related Products
Description
Phoenix Contact 1600030 The female connector has a nominal voltage of 400 V and a nominal current of 13.5 A with 10 connections and 10 positions available for use. It features crimp connections, with a rated cross-sectional area ranging from 0.2 mm² to 4 mm² and is mounted using direct screw connection. The component's outer shell color is gray.
Specifications
Terminal Block Indication
No Indicator
Terminal Block Voltage Rating
400 Volt
Terminal Block Fused
Not Fused
Terminal Block Width
92 mm
Terminal Block Number of Levels
1
Terminal Block Number of Connections
10
Terminal Block Component Color
Gray
Terminal Block Grounded
Not Grounded
Terminal Block Max Wire Size
12
Terminal Block Min Wire Size
24
Terminal Block High-current
High-current Terminal Block
Terminal Block Connection Method
Crimp Connection
Component
Terminal block
Manufacturer
Phoenix Contact
Terminal Block Amperage
13.5 Amp
Sub Component
High current terminal block
Sub Component
Female Insert
