Phoenix Contact 1096429 Timer relay MACX-TR-1T-MUL
Normally In Stock
Code: 69038
Phoenix 1096429 Timed relay 2floatingPDTcontacts 24 VAC/DC - 240 VAC/DC (-15% - +10%) Screw connection Input Function Relays
Condition: New
Usually ships within 7-14 days. Call for ship time.$163.75
Sale Price
$136.46
Tariff Status
Tariff may apply if shipping to the United States. Tariff costs are calculated and will be displayed in the shopping cart.
Need a large quantity or a custom solution?
Add this product to your job, favorites list or request a quick quote for volume pricing and lead time information. Our team is ready to assist with any special requirements.
Description
Phoenix Contact 1096429 The device features a wide-range power supply from 24V AC/DC to 240V AC/DC, with 13 functions that include adjustable time, IP and II functions, as well as support for dry contacts, PNP and NPN proximity switch inputs, two PDTs, and password protection, all accessible through screw connections.
Specifications
Relay Throws
Double Throw
Relay Mounting
Din Rail
Relay Connection Type
Screw Connection
Relay Application
Input Function
Floating (Isolated Dry Contacts)
Floating Isolated Contacts
Relay Contact Material
AgNi (90-10)
Relay Poles
Double Pole
Relay Timing Range
1
Manufacturer
Phoenix Contact
Component
Timer Relay
Relay Load Voltage AC Rating
400 Volt
Coil Voltage Rating
24-240 Volt
