Phoenix Contact 1033727 Type 2 surge protection plug VAL-MS 1500DC-PV-ST
Normally In Stock
Code: 71908
VAL-MS 1500DC-PV-ST Phoenix 1033727 Replacement plug 1500 VDC pluggable Type 2 surge protection plug Surge Protection *NON-CANCELLABLE, NON-RETURNABLE*
Condition: New
Usually ships Same Day or Next Day*NON-CANCELLABLE, NON-RETURNABLE*
$104.83
Sale Price
$87.36
Tariff Status
Tariff may apply if shipping to the United States. Tariff costs are calculated and will be displayed in the shopping cart.
Need a large quantity or a custom solution?
Add this product to your job, favorites list or request a quick quote for volume pricing and lead time information. Our team is ready to assist with any special requirements.
Description
Phoenix Contact 1033727 Replacement plug set comprising three units suitable for pairing with PV arrester combinations within the VAL-MS 1500DC-PV product line.
Specifications
Max Discharge Capacity
80 A
Fault Warning
Optical
Fault Warning
remote indicator contact
Arrester Class according to IEC
II
Arrester Class according to IEC
T2
Manufacturer
Phoenix Contact
Connection Method
Screw connection
Surge Protector Type
Surge arrester
Maximum Continous Voltage
800 Volt
Nominal Discharge Current
15 kA
Surge Protector Line Voltage
1500 Volt
Component
Surge Protection Plug
Features
Optimum inverter protection, thanks to low protection level
Reliable contact, thanks to integrated rotating latch
Easy replacement, thanks to plug-in arresters
Increased safety, thanks to compliance with standard EN 50539-11
Efficient replacement of defective plugs, thanks to visual status indicator
Protection against mismatching, thanks to keyed plugs and base elements
