Phoenix Contact 2907921 Type 3 surge protection plug PLT-SEC-T3-60-P-UT/PT
Normally In Stock
Code: 71956
PLT-SEC-T3-60-P-UT/PT Phoenix 2907921 Replacement plug 60 VAC pluggable Type 3 surge protection plug Surge Protection
Condition: New
Usually ships Same Day or Next Day$174.72
Sale Price
$145.60
Tariff Status
Tariff may apply if shipping to the United States. Tariff costs are calculated and will be displayed in the shopping cart.
Need a large quantity or a custom solution?
Add this product to your job, favorites list or request a quick quote for volume pricing and lead time information. Our team is ready to assist with any special requirements.
Description
Phoenix Contact 2907921 Replacement surger protection plug available in the PLT-SEC…-UT/PT product line, designed for use with a nominal voltage of 60V.
Specifications
Fault Warning
Optical
Arrester Class according to IEC
C1
Arrester Class according to IEC
C2
Arrester Class according to IEC
C3
Direction of Action
Line-Earth Ground
Manufacturer
Phoenix Contact
Connection Method
Screw connection
Maximum Continous Voltage
150 Volt
Surge Protector Type
Surge protection for measurement and control technology
Nominal Discharge Current
2.5 kA
Surge Protector Line Voltage
60 Volt
Component
Surge Protection Plug
Features
Powerful protection for AC and DC applications enables use in a variety of applications
Disconnect device provides increased safety in the event of electrical and thermal overload
Information concerning the status of the protective device is always available by means of visual and mechanical status indicator and remote indication contact
Pluggable protective devices enable easy maintenance
Downloads
Phoenix 2907921 CAD data International.dxfPhoenix 2907921 CAD data International.pdfPhoenix 2907921 CAD data International.stpPhoenix 2907921 Flyer English-2.pdfPhoenix 2907921 Flyer English.pdfPhoenix 2907921 Manufacturers declaration International.pdfPhoenix 2907921 Surge Protection English.pdfPhoenix 2907921 Tender Text English.zip
