Phoenix Contact 2701030 Base unit NLC-050-024D-06I-04QTN-00A
Normally In Stock
Code: 723954
Phoenix Contact NLC-050-024D-06I-04QTN-00A - Base unit, DIN Rail Mount - 2701030
Condition: New
Usually ships Same Day or Next Day$172.49
Sale Price
$143.74
Tariff Status
Tariff may apply if shipping to the United States. Tariff costs are calculated and will be displayed in the shopping cart.
Need a large quantity or a custom solution?
Add this product to your job, favorites list or request a quick quote for volume pricing and lead time information. Our team is ready to assist with any special requirements.
Description
Phoenix Contact 2701030 The Nanoline base unit features 6 digital inputs and 4 NPN digital outputs, serving as the core device with an expandable capability through up to three I/O extension modules that can add additional input/output channels. Furthermore, optional communication modules offer network or serial connectivity options, while a user-friendly Operator Panel provides intuitive interaction for users. The unit is programmed using nanoNavigator software, allowing for efficient and controlled operation of the system.
Specifications
Component
Base Unit
Manufacturer
Phoenix Contact
PLC & IO Mounting Type
DIN Rail
Features
Basic unit has integrated digital inputs, relay outputs, and analog inputs, including high-speed counters
An operating panel can be optionally integrated in the basic unit or installed on a wall in a decentralized manner
Intuitive programming language with options for flowcharts and ladder diagrams
