Phoenix Contact 2924294 Isolation switch amplifier MACX MCR-SL-2NAM-RO-SP
Normally In Stock
Code: 73102
MACX MCR-SL-2NAM-RO-SP Phoenix 2924294 Isolation amplifier
Condition: New
Usually ships Same Day or Next Day$272.50
Sale Price
$227.08
Tariff Status
Tariff may apply if shipping to the United States. Tariff costs are calculated and will be displayed in the shopping cart.
Need a large quantity or a custom solution?
Add this product to your job, favorites list or request a quick quote for volume pricing and lead time information. Our team is ready to assist with any special requirements.
Related Products
Description
Phoenix Contact 2924294 The NAMUR 2-channel signal conditioner is a device that enables the operation of proximity sensors and switches at the control level through relay outputs with N/O contacts. It features line fault detection and provides 3-way electrical isolation for added safety, meeting SIL 2 standards. Additionally, it utilizes push-in connections for convenient installation.
Specifications
Safety Connection Method
Push-in connection
Safety Interfaces
Proximity Switches
Safety Degree of Protection
IP20 (not assessed by UL)
Safety Contact Type
1 N-O contact per channel
Sub Component
Isolating switch transf.
Manufacturer
Phoenix Contact
Component
Isolation amplifier
Features
Line fault detection (LFD), can be activated/deactivated, error indicated by flashing red LED with de-excitation of output relay
Up to SIL 2 in accordance with EN 61508
Installation in zone 2, protection type "n" (EN 60079-15) permitted
Power supply and error indication possible via DIN rail connector
LED indicators for supply voltage, switching state, and malfunction in accordance with NAMUR NE 44
Direction of operation can be selected (operating or closed circuit current behavior)
3-way electrical isolation
2-channel
Relay signal output (N/O contact)
Input for NAMUR proximity sensors (EN 60947-5-6), floating contacts or contacts with resistance circuit
