Phoenix Contact 1105102 PSR-M Base Module Gateway
Normally In Stock
Code: 73121
Seamlessly connects PSR-M modules via PROFINET and TBUS, featuring a push-in terminal block with integrated TBUS connector
Condition: New
Usually ships Same Day or Next Day$504.29
Sale Price
$420.24
Tariff Status
Tariff may apply if shipping to the United States. Tariff costs are calculated and will be displayed in the shopping cart.
Need a large quantity or a custom solution?
Add this product to your job, favorites list or request a quick quote for volume pricing and lead time information. Our team is ready to assist with any special requirements.
Related Products
Description
The Phoenix Contact 1105102 gateway enables seamless connectivity between lower-level PSR-M base modules and higher-level controllers via PROFINET, TBUS, and other interfaces. It features a push-in terminal block with an integrated TBUS connector for efficient installation
Specifications
Safety Degree of Protection
IP20
Safety Connection Method
Push-in connection
Safety Interfaces
TBUS
Safety Network Interface
PROFINET
Safety Connection Method
RJ45 jack
Safety Connection Method
USB 2.0 Hi-Speed
Safety Transmission Speed
100 Mbps
Component
Gateways-Proxies
Manufacturer
Phoenix Contact
Sub Component
Data interface
Safety Relay Supply Voltage
24 VDC -20 % - +20 % (external fuse
Safety Relay Supply Voltage
typically 4 A)
Features
Low housing width of just 22.6 mm
Fast startup, thanks to easy hardware and software configuration
Machine downtimes minimized with comprehensive, easy-to-understand diagnostics
Cost-effective safety solution with a high level of adaptability to individual requirements
Tool-free and time-saving installation thanks to Push-in technology
