Omega CDE-440-01 Conductivity Sensor
Normally In Stock
Code: 830601
Omega CDE-440-01 Conductivity Sensor
Condition: New
Usually ships Same Day or Next Day$978.82
Sale Price
$815.68
Tariff Status
Tariff may apply if shipping to the United States. Tariff costs are calculated and will be displayed in the shopping cart.
Need a large quantity or a custom solution?
Add this product to your job, favorites list or request a quick quote for volume pricing and lead time information. Our team is ready to assist with any special requirements.
Description
Conductivity Sensor, 0.1 μS to 20 mS, 3/4 " NPT Male, 316 SS, 130 °C (266 °F), CDE-440 Series, Each
Specifications
Manufacturer
Omega Engineering
Component
Conductivity Sensor
Features
Additional Features 1Anti-Corrosion Treatment: Finished with electrostatic epoxy paint
Conductivity1 μS/cm to 2 S/cm
Data InterfaceRS485 Modbus
Display ModeContinuous, average or hold
Display Type2 lines with 16 characters LCD
Enclosure RatingsIP68, NEMA Type 4
Frequency50/60Hz
Galvanic Isolation2000 Vac
Housing MaterialAluminum, ABS
Impedance600 Ω
Measurement TypeConductivity
Operating Temperature, Max40 °C
Operating Temperature, Min5 °C
Output Detail2 N.O. (1A/240 Vac) on/off alarm or PWM
4 to 20 mA for PID control or retransmission
Power Consumption3.5 VA
Process Connection Material316 Stainless Steel
Process Connection Size3/4 in
Process Connection TypeNPT Male
Process Temperature, Min0 °C
Process Temperature NoteAutomatic or Manual Temperature Compensation: 0 to 100°C (32 to 212°F) Temperature Compensation: NTC-R typical 5 Ω at 25°C (77°F
Resistance10 MΩ
Resolution0.1 or 0.01
Supply Voltage90 to 240 Vac
Weight1.3 kg
