Phoenix Contact 1215394 Axioline I/M Analogue Module
Normally In Stock
Code: 836878
This industrial module inputs varying currents up to 20mA with secure 100Mbps local bus transmission and IP20 protection
Condition: New
Usually ships within 7-14 days. Call for ship time.*NON-CANCELLABLE, NON-RETURNABLE*
$978.98
Sale Price
$815.82
Tariff Status
Tariff may apply if shipping to the United States. Tariff costs are calculated and will be displayed in the shopping cart.
Need a large quantity or a custom solution?
Add this product to your job, favorites list or request a quick quote for volume pricing and lead time information. Our team is ready to assist with any special requirements.
Description
The Phoenix Contact 1215394 Axioline F is a passive analog input module with 8 channels, offering varying current ranges from 0 mA to 20 mA. It features 2-conductor connection technology, operates at 100 Mbps, and includes HART functionality, providing reliable performance in extreme conditions
Specifications
PLC & IO Degree of Protection
IP20
PLC & IO Transmission Speed
100 Mbps
PLC & IO Connection Method
Push-in connection
Manufacturer
Phoenix Contact
Component
Analog Module
PLC & IO Type
Axioline F
Features
Passive analog input module
Sinks power from up to eight HART enabled, active analog input signals
Cyclic access to PV, SV, TV, QV, and Loop Current
Current ranges: 0 mA ... 20 mA, 4 mA ... 20 mA
Can be used under extreme ambient conditions
Extended temperature range of -40 °C ... +70 °C (see “Tested successfully: use under extreme ambient conditions” in the data sheet)
