Schneider Electric EGB16030 E-Frame Breaker for Square D NF Panelboards
Normally In Stock
Code: 91481
Schneider EGB16030 30 A Circuit-breaker EGB 18 kA 600Y/347 VAC 125 A Frame EDB-EGB-EJB 1 1 00936 - EGB CIRCUIT BREAKERS 30.09 lbf.in (3.4 N.m 0.00-0.02 in² (2.5-16 mm² AWG 14-AWG 6 5.66 in (143.76 mm 4.05 in (102.87 mm 0.98 in (24.89 mm DE2 00785901238409 1 1.31 lb(US (0.59 kg Ye
Condition: New
CALL FOR LEAD TIME$321.38
Sale Price
$267.82
Tariff Status
Tariff may apply if shipping to the United States. Tariff costs are calculated and will be displayed in the shopping cart.
Need a large quantity or a custom solution?
Add this product to your job, favorites list or request a quick quote for volume pricing and lead time information. Our team is ready to assist with any special requirements.
Description
E-Frame Breakers, part of Square D's NF Panelboards, offer robust features providing superior overload and short circuit protection with thermal-magnetic trip units and signal indicators indicating when a trip occurs, mounting bolts secure them in place, and various accessories are available for this breaker which operates at 600Y/347 VAC, has a maximum interrupt rating of 65 kA at 120 VAC, holds current up to 270A, trips at 875A, and is UL Listed and HACR rated.
Specifications
Breaker Amperage Rating
30 Amp
Breaker Number of Poles
Single Pole
Breaker Voltage Rating
600Y VAC
Breaker Voltage Rating
347 VAC
Component
Miniature Circuit Breaker
Manufacturer
Schneider Electric
Manufacturer
Square D
Features
Used in lighting panelboards
Superior overload and short circuit protection
From 15A to 125A ratings
