Schneider Electric EDB16025 Square D E-Frame Breaker
Normally In Stock
Code: 91570
Schneider EDB16025 25 A Circuit-breaker EDB 14 kA 600Y/347 VAC 125 A Frame EDB-EGB-EJB 1 1 00931 - EDB CIRCUIT BREAKERS 30.09 lbf.in (3.4 N.m 0.00-0.02 in² (2.5-16 mm² AWG 14-AWG 6 5.66 in (143.76 mm 4.05 in (102.87 mm 0.98 in (24.89 mm DE2 00785901238454 1 1.3 lb(US (0.59 kg Yes
Condition: New
CALL FOR LEAD TIME$196.10
Sale Price
$163.42
Tariff Status
Tariff may apply if shipping to the United States. Tariff costs are calculated and will be displayed in the shopping cart.
Need a large quantity or a custom solution?
Add this product to your job, favorites list or request a quick quote for volume pricing and lead time information. Our team is ready to assist with any special requirements.
Description
E-Frame breakers, part of Square D NF Panelboards, offer robust features specifically designed for overload and short circuit protection in a wide range variety, with thermal-magnetic trip units and signal indicators that alert when a trip occurs, featuring 25A, 1 pole, 600Y/347 VAC operating voltage and 120VAC max interrupt rating, along with a hold current of 270A and trip current of 875A.
Specifications
Breaker Amperage Rating
25 Amp
Breaker Number of Poles
Single Pole
Breaker Voltage Rating
600Y VAC
Breaker Voltage Rating
347 VAC
Component
Miniature Circuit Breaker
Manufacturer
Schneider Electric
Manufacturer
Square D
Features
Used in lighting panelboards
Superior overload and short circuit protection
From 15A to 125A ratings
