Schneider Electric HLA36025 PowerPacT H-Frame Circuit Breakers
Normally In Stock
Code: 93173
Schneider HLA36025 Circuit breaker 25 A 3P 80 % I-Line IEC, UL Listed, CSA, CE PowerPact H L 350 A 750 A 9.73 in (247.14 mm 4.48 in (113.79 mm 4.36 in (110.74 mm 104 °F (40 °C ABC 250 V DC, 600 V AC, 500 V DC I-Line connection line, Lugs load 20 kA 250 V DC, 50 kA 500 V DC, 125 k
Condition: New
CALL FOR LEAD TIME$2531.12
Sale Price
$2109.27
Tariff Status
Tariff may apply if shipping to the United States. Tariff costs are calculated and will be displayed in the shopping cart.
Need a large quantity or a custom solution?
Add this product to your job, favorites list or request a quick quote for volume pricing and lead time information. Our team is ready to assist with any special requirements.
Description
PowerPacT H-Frame circuit breakers offer thermal magnetic or electronic protection units, providing up to 50kA breaking capacity at 600VAC, and feature dual-break rotating contacts for reduced peak current during short circuits, along with an integral push-to-trip button for manual tripping, available in various pole counts and I-Line constructions that meet UL, CSA, NOM, and IEC standards and are CE marked.
Specifications
Frame Type (Molded Case Breaker)
H Frame
Amperage (Molded Case Breaker)
25 Amp
Poles (Molded Case Breaker)
Three Pole
Interrupt Code (Molded Case Breaker)
L Interrupt Rating
Maximum Voltage (Molded Case Breaker)
600 VAC
UL Listing (Molded Case Breaker)
UL 489
Mounting (Molded Case Breaker)
I-Line
Maximum Voltage (Molded Case Breaker)
250 VDC
Maximum Voltage (Molded Case Breaker)
500 VDC
Manufacturer
Schneider Electric
Manufacturer
Square D
Component
Molded Case Circuit Breaker
Interrupt Rating (Molded Case Breaker)
50 kA 600 Volt
Interrupt Rating (Molded Case Breaker)
20 kA 250 Volt
Interrupt Rating (Molded Case Breaker)
50 kA 500 Volt
Interrupt Rating (Molded Case Breaker)
125 kA 240 Volt
Interrupt Rating (Molded Case Breaker)
100 kA 480 Volt
Features
Available in 2 or 3 pole design
Standard 80% or 100% rating
Available in Unit mount, I-line or Drawout constructions
