Dwyer 2-5000-1KPA Minihelic® II Differential Pressure Gauge
Normally In Stock
Code: 571998
Dwyer 2-5000-1KPA - Differential pressure gauge, range 0-1 kPa.
Condition: New
Usually ships Same Day or Next Day$84.83
Sale Price
$70.69
Tariff Status
Tariff may apply if shipping to the United States. Tariff costs are calculated and will be displayed in the shopping cart.
Need a large quantity or a custom solution?
Add this product to your job, favorites list or request a quick quote for volume pricing and lead time information. Our team is ready to assist with any special requirements.
Description
Dwyer 2-5000-1KPA Minihelic® II Differential Pressure Gauge is a reliable and accurate gauge for measuring pressure in air and compatible gases. With an operating temperature range of 20 to 120°F (-6.67 to 48.9°C) and an accuracy of ±5% of FS at 70°F (21.1°C), this gauge is suitable for various applications. The housing is made of glass-filled nylon with a polycarbonate lens, ensuring durability and longevity. The pressure limit is 30 psig (2.067 bar), and the gauge can be mounted with the diaphragm in a vertical position. Other mounting orientations are available upon request.
Specifications
Manufacturer
Dwyer
Component
Differential Pressure Gauge
(Instrument-Sensor) Application
Air and Compatible Gases
(Instrument-Sensor) Temperature Range
20 - 120°F/-6.67 - 48.9°C
(Instrument-Sensor) Measurement Accuracy
5.0%
Features
Removable lens and rear-housing provides easy, cost-effective servicing
Accuracy and value provides an excellent solution for OEM and user applications
Durable housing materials make it well-suited for rough environments and total high pressure
